Colchester Triumph VS2500

FULLY REFURBISHED COMPLETE WITH NEW DRIVE!

CAPACITY
Swing over bed	400mm	15.7″
Swing over cross slide	246mm	9.6″
Height of centres	195mm	7.7″
Swing in gap	585mm	23″
Gap width from faceplate	165mm	6.5″
Bed length	1270mm	50″
Distance between centres	1270mm	50″

SPINDLE
Spindle nose	D1 – 6 Camlock	D1 – 6 Camlock
Taper in spindle nose bush	No 4 MT	No 4 MT
Spindle bore	54mm	2.1″
Maximum spindle speed	2500 rpm	2500 rpm
Spindle speed ranges
Low	14 – 300 rpm	14 – 300 rpm
Medium	36 – 830 rpm	36 – 830 rpm
High	109 – 2500 rpm	109 – 2500 rpm
Maximum spindle motor power	7.5kW	10 HP
Number of Imperial Pitches	56	56
Range of Imperial Pitches	2 – 56 TPI	2 – 56 TPI
Number of Diametral Pitches	20	20
Range of Diametral Pitches	8 – 56 DP	8 – 56 DP
Number of Metric Pitches	51	51
Range of Metric Pitches	0.2 – 14mm Pitch	0.2 – 14mm Pitch
Number of Module Pitches	20	20
Range of Module Pitches	0.2 – 3.5 MOD	0.2 – 3.5 MOD

TAILSTOCK
Tailstock quill taper	No 5 MT	No 5 MT
Tailstock quill travel	145mm	5.7″

SKU: 3472 Category: Lathes

Colchester Triumph VS2500

Buy our fully refurbished Colchester Triumph VS 2500 lathe, equipped with a new drive for enhanced performance. With a swing over bed of 400mm (15.7″) and a height of centre at 195mm (7.7″), it offers versatility for various workpieces. The spindle, featuring a D1-6 Camlock nose and 54mm (2.1″) bore, reaches speeds of up to 2500 rpm across low, medium, and high ranges, powered by a 7.5kW (10 HP) motor. Its comprehensive threading capabilities cater to imperial, diametral, metric, and module pitches, ensuring precision in machining. The tailstock, with a No. 5 MT quill taper and 145mm (5.7″) quill travel, further enhances accuracy. Ideal for diverse machining needs, the Colchester Triumph VS2500 combines reliability and efficiency in a compact package. Contact Us today for more information, or to make an enquiry.
